Wholesale Good Quality Low Cost Save Cost Adjustable Square Column Formwork Adjustable Steel Column Formwork

The square column buckle is composed of a specially customized matching clamp. Its shape is made up of a single galvanized clamp plate with four corresponding elbows. One end of the clamp plate is set as a bending structure. Each clamp plate is provided with several fixed holes at equal intervals along the length direction. The wedge-shaped fixed pins pass through the through holes and fixed holes to fix the limit sleeve and the clamp plate, forming a square column formwork fastener that is convenient for installation and disassembly
Availability:
Quantity:
Inquire Add to Basket

  • ZEEMO

Product descriptions from the supplie

Warning/Disclaimer
This product has acquired the relevant product qualification(s)/license(s) of certain applicable country/countries.View more
Product Description
Applicable:

Adjustable Column Clamps is an innovative steel formwork clamp, which is applicable to the reinforcement of cast-in-situ reinforced concrete square column formwork commonly used in engineering construction.Such as mall,hospital,warehouse ...

adjustable2


Specification

111

Clamp specifications(mm)
Model(#)
Total Length(mm)
Weight(kg)
400-600
8.0# steel
1161
21.6
500-800
8.0# steel
1361
26.2
500-800
10# steel
1361
48.14
700-1000
10# steel
1647
51
900-1200
10# steel
1847
57.2
1100-1400
10# steel
2047
65
1300-1600
10# steel
2247
70.4
1500-1800
10# steel
2447
115.8
1900-2100
10# steel
2747
129.8

Why Choose Us

No need Tie rod
Fast Installation and quick dismantling.Compared with the traditional method, the installation speed is increased by 4-6 times,save time and laber.
Standard shape
Angle is assured to be right. No deform happens.
7     elevation
Standard shape
Angle is assured to be right. No deform happens.
QQ201703031116591 (161)
Reused Many Times
To improve the adjustable column clamps strength and durability, we use Q355B galvanized steel. strength 355 MPA. From feedback on site, it's adjustable, easy handling, and reused for over 10 years.
Packing & Delivery
Packing details: Export package covered with waterproof shrinking film and craft paper, bundle with steel stripes outside or as customer request.
Delivery Details: 5-10 days after order
67)       22)
                    Pallet transportation                                                             Shock bubble film

Company Profile
gc
Shandong Zeemo Construction Technology Co Ltd,initiated from 1990's,is a multiple industry group engaged in the production and sales of Film Face Plywood,Construction Formwork Syetem,square and round column reinforcement,Scaffolding&Accessories,ect.The boss of our group is nominated as the president of China Shuttering Board Committee.
We have professional Production lines and International Technician teams with ISO9001:2015 management system.Our core advantage is to integrate different kinds of formwork products together to create the Intelligent Formwork Solutions for your project.We have modern and fast logistic network to deliver goods timely&cost effectively,the best technique support and service follows all the way.
_06 5_09
FAQ
Q1: Are you trading company or manufacturer ?
A1: We are factory.

Q2: How long is your delivery time?
A2: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q3: Do you provide samples ? is it free or extra ?
A3: sample is chargable, also the freight .

Q4: What is your terms of payment ?
A4: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance against copy BL
